KYTOLA金屬表管流量計,型號 ML
Overview
Metal Tube flow meter model ML s designed for medium and large liquid flows in rough conditions. It is compatible with a wide range of liquids. Reliable and accurate flow measurement is based on a variable area metering principle using a free-floating float.The ML meter withstands high pressure and has excellent temperature resistance. Typical applications are found in chemical and petrochemical industries, power plants and general flow measurement.
| Technical data | |
| Flow tube | Stainless Steel AISI 316L |
| Connectors | Stainless Steel AISI 316L |
| Float | Stainless Steel AISI 316L |
| Display housing | Aluminium (*Stainless Steel AISI 316L) |
| Housing window | Safety glass |
| Seals | Viton? |
| Pressure class | DIN/EN flanges PN40 ANSI/ASME flanges class 150 or class 300 (ML100: 150 lbs) Female threads 40 bar |
| Maximum temperature | +110°C without alarm sensors +100°C with NAMUR alarm sensors +80°C with PNP/NPN alarm sensors |
| Connections | DIN/EN 1092-1 PN40 form B1 (raised face) flange (ML100: PN16) ANSI/ASME B16.5 class 150 raised face flange ANSI/ASME B16.5 class 300 raised face flange G/NPT female thread 40 bar (only ML25, ML50) |
| Weight | 3.7 - 15.9 kg depending on model (aluminium display/housing, stainless steel display/housing add 1,6 kg). |
| Accuracy | ±5% F.S. (H?O at +20°C) |
| *) Special construction on request | |
